20 Sept 2021

Sony HCD-SA30 (AEP, UK Model)




Specs
sacd/dvd receiver (DAV-SA3 with speakers),
class D,
2x44W@6Ω/1kHz,
5x44@6Ω/1kHz + 1x80W@3Ω/100Hz,
Nichicon VR, Nippon Chemicon KZE / SMG / W components,
5.1 ch s-master,
cd/cd-r/cd-rw/dvd/dvd-rw,
DTS / DDPII,
fm/am,
Sony RM-SP400 remote,
video in/out,
--- dac / filter,
CDM77A-DVBU20 / DBU-1 transport / pickup,
CD 2–20000 Hz ± 1,0 dB,
DVD 2–22000 Hz ± 1,0 dB,
harmonic distortion ≤ 0,03%,
mm 355x75x360, kg 5,9.


7 Mar 2021

PS Audio Trio A-100






Specs
2x100W@8Ω/20-20000Hz,
2x200W@4Ω/20-20000Hz,
2x B&O ICEpower 200ASC power amp board (class D),
smd components,
Elna RJB / RJF, Rifa components,
rca / xlr,
dual mono,
mono bridge,
mm 215x75x390, kg 3,2.


24 Jan 2018

B&W 705












Specs
2-way configuration,
bass reflex via front-firing port,
woven Kevlar cone midwoofer B&W LF00027 165mm,
(die cast frame, rubber surround),
alloy dome tweeter B&W HF00129 25mm,
(time-aligned, ferrofluid cooled),
50-120W@8Ω,
46-25000Hz ±3 dB,
sens. 89 dB,
mm 222x421x319, kg 9,5.


7 Dec 2017

Cambridge Audio Azur 540R v1





Specs
100Wx2@8Ω/20-20000Hz,
80Wx6@8Ω/20-20000Hz,
12x B817 D1047 power transistors,
toroidal power transformer,
2x10000µF Samxon LP filter caps,
Samxon GR / GS components,
dsp mode, DTS-ES/DPL2/DD-EX codec,
Cirrus Logic CS42518 24bit/192kHz delta-sigma 8 dac / 2 adc,
Cirrus Logic CS493263 dsp,
Cambridge Audio RC-540D remote,
fm/am tuning,
mm 430x100x310, kg 9,5.


28 Jul 2016

Nokia 6600 (off-topic)




Specs
Symbian 7.0 os (Series 60 v2.0 UI),
ARM9 104 MHz cpu,
2,1" TFT 16kcol display, 176 x 208, 130 ppi,
6 MB ram, MMC slot,
BT 1.1, IrDA, GSM, GPRS, HSCSD,
850 mAh battery,
mm 109x58x24, kg 0,122.
|
0.3 MP VGA 640 x 480 camera,
video recording.


22 Dec 2014

Sony STR-DE497 (CEL area)







Specs
50Wx5@8Ω/20-20000Hz,
 80Wx5@8Ω/1kHz,
10 Sanken MP1620 MN2488 power transistors,
2x4700µF Nichicon VR Gold filter caps,
Elna, Jamicon SK, Lelon components,
DPL/DPLII/DD/DTS codec,
AKM AK4628VQ 2ch/24bit/96kHz adc, 8ch/24bit/192kHz dac,
Sony CXD9617R 32bit dsp,
Sony RM-U306B remote,
fm/am tuning,
mm 430x145x310, kg 7,5.


16 Sept 2011

Sony TA-FB940R

immagine Sony



Specs
2x70W@8Ω/20-20000Hz,
2x2 J200 K1529 power transistors,
2x10000µF Nichicon Gold Tune filter caps,
Nichicon FW Gold, Elna components,
toroidal power transformer,
mm 430x150x420, kg 10,3.
